Purpose
To understand what habitats we have, and how they are functionally connected, as a guide to how species can, or could, travel between habitats for feeding, over-wintering, breeding, or offspring moving away from parents. This helps identify where we can make better, bigger, more and joined up space for nature.
How to use these layers
This layer provides an idea of current functional connectivity of semi-natural habitat in Dorset and possible opportunities to expand habitats and increase connectivity.
How these layers were created
Background
The ecological network mapping was originally undertaken by Dorset National Landscape in 2012 and updated in 2018. It covers the county of Dorset and is recent enough to be used for the local nature recovery strategy. All modelling is based on the best available data and not intended to be a perfect representation of reality on the ground, so it wouldn’t have been worthwhile to spend more time and money updating this baseline data.
The Dorset National Landscape’s ecological network mapping was based on least-cost modelling work developed by Forest Research (commonly known as ‘BEETLE’), described in Watts et al., 2005 and Eyecott et al., 2007. The contract was delivered by Environment Systems, overseen by a steering group made up of Wessex Water, Dorset Catchment Partnership, Bournemouth Borough Council, Dorset County Council, Dorset Wildlife trust, Cranborne Chase National Landscape, Dorset National Landscape, Borough of Poole, and Dorset Local Nature Partnership.
Land cover
A land cover map of Dorset was produced using local data and expertise. Gaps were filled with data derived from remote sensing, principally through Sentinel 1 and 2 satellite imagery. A combination of two seasonal images were used to allow better differentiation between habitat types due to their different phenology. Topographic data, in the form of a 5m digital terrain mode, was used to aid interpretation. This analysis allowed land cover to be categorised into arable, coastal, improved grassland, heathland, scrub, urban, semi-improved grassland, water, wetland, woodland (broadleaved), and woodland (coniferous).
The complete land cover map was then refined with analysis of Ordnance Survey MasterMap, previous land cover mapping data from 2011, and underlying geology data. The map was validated and the process re-run, through expert analysis within Dorset Environmental Records Centre (DERC) and quality control carried out by the consultants. At this point a minimum mapping unit was applied to remove very small polygons.
This identified 163 habitat classes (using the Integrated Habitat System) which were simplified into 30 legend classes, for which total habitat areas were calculated. Note the total area of all habitat classes in this data adds up to 14 hectares more than the total area of Dorset, due to the inclusion of a few habitat areas that start within Dorset but go just over the county boundary.
Using the land cover data as a basis, ecological networks for five semi-natural habitat types were created: semi-natural grassland, broadleaved woodland, lowland heathland, wetland, and coastal. You can view the habitat classes used to define these networks by downloading this Guide to Dorset's nature recovery maps as a PDF and going to appendix B.
Core habitats
A minimum size threshold of 1ha was used to define ‘core habitats’. Smaller areas were classed as ‘stepping stones’. Stepping stone habitats are the same habitat type as core habitats but are considered too small to support viable populations in their own right.
In the case of the woodland and heathland networks, it was considered that a simple selection of polygons greater than 1ha may not capture all the effective core habitat, as these habitat patches tend to be fragmented by tracks and roads, forming a patchwork appearance.
In these cases, excluding areas under 1ha may miss areas that are still functionally connected and acting as core habitat. For this reason, a 5m buffer was applied to areas of woodland and heathland and the combined area of overlapping areas used to ascertain whether they should be classed as either core or stepping stone habitat.
Functional connectivity
After identifying the core habitats, landscape permeability was analysed to assess how areas surrounding the core habitats facilitate the movement of species, or present barriers.
This analysis acknowledges the dependency of species populations on the wider landscape for a variety of purposes such as feeding, over-wintering, and dispersal of offspring for example, and maintaining the flow of genetic material between populations to build ecological resilience.
Each habitat class was assigned a landscape permeability score against each of the four network types. For example, wet heath: this is lowland heathland core habitat, so was assigned a score of 1 (no resistance to movement for a typical heathland species). For wetland it was given a score of 2 (almost no resistance to movement for heathland species). However, semi-natural grassland and broadleaved woodland were given higher scores of 30 and 25 respectively, reflecting the increased resistance to movement these habitats give to heathland species. This process was applied to all 163 habitat classes and was based on best available data at the time of production. The scoring sheet is available on request.
A movement cost model was then applied using core habitat patches as the start / source locations, producing seamless landscape-scale permeability raster datasets for each of the core habitat type ecological networks. The data can be adjusted to model the effective networks for both generic and specific species, if the foraging / dispersal distance of a species is known, to create buffers that surround and connect the core networks which represent the hostility of the landscape matrix to species dispersal.
A maximum dispersal distance of 2km was used to map the current functional connectivity of habitats in Dorset. The width of the buffer is constrained by the surrounding land’s its ability to allow species movement, so in some places is only 40m.
A maximum buffer of 5km was used to show opportunities to make existing core habitats bigger and more joined up.
An additional maximum buffer of 20km was added for grassland, heathland and woodland, although not based on strong ecological principles it represents an opportunity to improve habitat connectivity everywhere.
For heathland, the 2km and 5km buffers were refined using information about suitable geology/soils for heathland habitat creation.
For coastal habitats, a buffer strip was created from the core coastal and intertidal habitats to represent species movement up to a maximum of 100m or up to 1km where this extended into flood zone 2. The focus of this buffer is well-connected to the other semi-natural habitat in-land, rather than suggesting all locations within that buffer are places to actually create coastal or intertidal habitats. Although this may happen in some places as the coastline changes overtime.
Super-core areas of over 100ha were identified from the core areas of semi-natural heathland, wetland, grassland and woodland. The 5km buffers for these habitat areas were combined to identify ways to expand and improve connectivity between the largest existing areas of semi-natural habitat. These inputted into selection of the high opportunity nature areas of the local habitat map.
Although rivers are included in the ecological network as they flow right across Dorset, local experts suggested key areas for river habitat enhancement or restoration in Dorset could be highlighted in flood zone 2 in the potential activities layer of the local habitat map. This is because flood zone 2 captures the widest extent of floodplain, bringing opportunities to create floodplain habitats and improve floodplain connectivity. In Dorset, chalk streams are also a key focus for habitat enhancement.
Extra wetland or peatland opportunities
In addition to the wetland ecological network above, some extra opportunities for wetland habitat were identified through the following local knowledge and projects:
- areas for wetland or peatland drawn based on Natural England local officer knowledge and advice
- peat restoration potential sites identified by Dorset Peat Partnership
- areas identified by Natural England and Environment Agency local knowledge as being likely to contain seepage springs, which are valuable wetland features
